Elsema MultiCode MCR91502R 915MHz 2 Channel Plug-In Receiver

Elsema MCR91502R 915MHz 2 Channel Receiver Specifications

Elsema MCR91502R 915MHz Receiver Compatibility

• Compatible with Elsema transmitters within the 915MHz frequency range
• Works seamlessly with gates, garage doors, lighting systems, and industrial setups
• Designed to operate multiple receivers and transmitters in close proximity without interference

Elsema MCR91502R 915MHz Receiver Features

The **Elsema MCR91502R 915MHz 2 Channel Receiver** is designed to provide reliable, interference-free control for a wide range of applications. With its advanced fast frequency hopping technology, the MCR91502R ensures reduced interference by operating between 915-928MHz, making it ideal for environments with multiple wireless devices. This receiver offers secure digital coding options, including a 12-way dipswitch for traditional setups and encrypted coding for enhanced security. Its low current consumption and wide operating voltage make it both energy-efficient and adaptable to various power setups.
Built for versatile applications, the MCR91502R’s 9 selectable user modes can be configured through a convenient 4-way dipswitch, offering functionality for both simple and complex control requirements. With a robust IP66 rating, it’s suitable for both indoor and outdoor installations. From remote lighting control to industrial automation and secure access control, this receiver’s flexibility and reliability meet diverse needs.

• Fast Frequency Hopping: Reduces interference or jamming across 915-928MHz.
• Multiple Coding Options: Digital 12-way dipswitch or encrypted coding for added security.
• Low Power Consumption: Operates on a broad voltage range with efficient power usage.
• Signal Indicator: On-board red LED confirms signal reception.
• High Stability: Crystal-controlled for precise, stable operation.
• 9 User Modes: Configurable via a 4-way dipswitch, offering tailored functionality.
